The CAD software for the metal trade

For metal construction, locksmiths and companies in the trades, metal technology or precision engineering: TENADO METALL 2D and TENADO METALL 3D are two independent CAD solutions, tailored to the metal trade. Each of them covers important task areas in the design process.

The CAD software for the metal Trade

Material-oriented work | Drawing with profiles, rods and surface material.
Live evaluation | Parts and sawing lists up to date.
Generators | Gates, fences, gratings, stairs, connections and railings
Teamwork | TENADO METALL 2D and TENADO METALL 3D work together perfectly.
Interfaces | Easy file transfer to customers or CNC machines. Whether as DWG/DXF, 3D PDF or STEP.
Libraries | Save thousands of components as favorites.

Work material-oriented

The construction elements in TENADO METALL have the properties that your material in storage also has – shape, size, weight, specific material density and much more. Each construction automatically has all material properties with it.

Operate intuitively

We speak metalworking

They are already familiar with the program, even though they have never worked with it: rods and profiles are sawn through, sawed off, mitred or joint trimmed. Fillings are called surface material and perforated sheets.

Get started intuitively

Getting started with TENADO METALL will be easy, even if you are used to other programs. This is ensured by our intuitive drawing tools, which will seem like old friends to you.

Reach your destination faster

Whether tutorials, instructional videos or our basic and advanced training courses here in Bochum: we will help you to get started quickly with TENADO METALL. If you have any questions, you can count on free support.

With TENADO METALL 2D you are already working with the design on the PC with materials that are automatically listed in parts and sawing lists. You can create offers faster and more professionally than your customer would ever dream of. You enter the most important data and TENADO METALL 2D draws for you.

With TENADO METALL 3D you can now design with numerous industry-relevant tools and functions.

You work material-oriented and construct directly with rods, profiles and frames. You can control all functions completely variably and flexibly.

Virtual Reality

A world full of new possibilities. With TENADO VR you can edit your construction in a completely different way. Use the VR glasses or a large screen to show your customers what it’s like when the model is really live in front of you. Edit and analyze your drawing down to the smallest detail. Pick up individual parts and swap them out.

The parts catalog

TENADO PARTS is the perfect addition to your drawing software. Whether heavy-duty fasteners from Würth or screws from Bossard, with TENADO PARTS you have access to over 800 manufacturer-certified product catalogues. Integration and evaluation are done quickly and easily. And of course numerous elements according to the DIN standard are also included. Everything constantly updated and up to date.

Stair construction

TENADO STATIK is your partner for reliable and comprehensive measurements based on a finite element analysis. Check your design for stresses, strains, critical loads and fatigue in a few simple steps. The ADD ON is integrated directly into TENADO METALL 3D. You just choose the type of analysis, determine the material and the boundary conditions, and TENADO STATIK does the rest. At the end, a detailed and comprehensive evaluation awaits you, including graphics and animations.

Structural analysis software

With TENADO STAIRS you can create stringer and stringer stairs in no time at all – fully automatically and without drawing. Simply specify the stair type, material and dimensions, and TENADO STAIRS will take care of the rest. You still determine everything yourself: individual rail constructions or stairs with profile stringers exactly according to the standard, fixed step widths and the step distribution. TENADO STAIRS make construction quick and easy.

Gears made easy

TENADO presents a real work simplification for designers from mechanical engineering, engineering and metalworking! TENADO GEARS, the new ADD ON for our 3D CAD software, specializes in the creation of individual gears, toothing or entire gears.
